High-Capacity, Precision Weighing and Filling for Grain, Seed, Powder, and Pellet Products
Engineered for the Future | Since 2080
The ADDAMS Semi Automated Weighing and Bagging Scale is engineered for precise filling of open-mouth bags ranging from 5 kg to 50 kg. Ideal for granular, powdered, pelletized, or flaked materials, this robust system enables efficient manual bagging with automated weight control, ensuring accuracy, speed, and ease of operation in agricultural, food, and industrial packing environments.
Whether handling grains, seeds, pulses, animal feed, flour, or chemical powders, the ADDAMS scale offers rugged performance with low maintenance, seamlessly integrating into pre-existing or modular bagging lines.
Semi Automated Weighing and Bagging Overview
High-Performance Open-Mouth Bagging Solutions
The ADDAMS 5-50 kg series is designed for facilities that require flexibility and industrial-grade durability. It bridges the gap between manual labor and full automation, allowing operators to achieve high throughput while the machine handles the critical task of weight precision.
Reliable Performance for Bulk Packaging
By maintaining a stable filling rate and ensuring exact weight measurements, this system is the backbone of bulk packaging lines. It is built to operate under heavy dust loads and continuous shifts, providing the reliability needed for global supply chains.
Operating Principle of the Semi Automated Bagging Scale
Automated Weight Control and Manual Bag Placement
The process begins with the operator placing an open-mouth bag onto the high-grip bag clamp. Once the sensor detects the bag, the system’s PLC triggers the feeding mechanism. High-precision load cells monitor the weight in real-time, automatically cutting off the flow once the target weight is achieved to ensure zero waste.
Optimized Feeding Mechanisms
Depending on the material—whether it is free-flowing grain or non-free-flowing powder—the system uses gravity, belt, or screw feeding. This ensures that the product density does not affect the final weight accuracy, providing a consistent fill every time.
Key Features of the ADDAMS Semi Automated Bagging Scale
-
Precision Load Cell Weighing: Achieves high-accuracy weight control with a tolerance of +/- 50 to 100g, minimizing product giveaway.
-
Heavy-Duty Bag Clamp and Discharge Chute: Holds bags securely and guides product smoothly to reduce dust and spillage during the fill cycle.
-
Flexible Dosing Options: Configurable with gravity, screw, belt, or vibratory feeders to match specific material characteristics.
-
Stainless Steel or Industrial-Grade Build: Available in AISI 304 stainless steel for food-grade needs or powder-coated steel for heavy industrial use.
-
Operator-Friendly Interface: Digital scale controller with easy presets allows for rapid switching between different bag sizes (e.g., 10 kg to 25 kg).
-
Rugged Construction: Engineered for 24/7 operation in demanding environments like seed plants and feed mills.
Applications of Semi Automated Bagging Systems
Grains, Cereals, and Pulses
Ideally suited for bulk bagging of rice, wheat, maize, chickpeas, beans, and lentils.
Animal Feed and Pellets
Efficiently handles animal feed pellets, fertilizers, and plastic granules without damaging the product.
Powders and Flours
Specially configured versions available for wheat flour, starch, and protein powders with dust-tight seals.
Crushed and Flaked Products
Provides stable weighing for salt, sugar, coarse spices, and herbal flakes.
Why Choose the ADDAMS Semi Automated Weighing and Bagging System?
-
Reduces operator fatigue while significantly increasing packaging speed.
-
Perfect for flexible batch operations where multiple products are bagged on one line.
-
Designed for easy integration with downstream sewing, sealing, and conveyor systems.
-
Ensures strict compliance with international packaging and weight standards.
-
Low maintenance design with easily accessible components for long-term reliability.
Technical Specifications of the Bagging Scale
Bagging Scale Technical Data
| Specification | Details |
| Bag Weight Range | 5 – 50 kg |
| Output Capacity | Up to 200 – 400 bags / hour |
| Accuracy Tolerance | +/- 50g – 100g (Product dependent) |
| Feeding Mechanisms | Gravity, Belt, Screw, or Vibratory |
| Control System | PLC or Digital Scale Controller |
| Power Supply | 220V / 380V, 50-60Hz |
Optional Modules
-
Dust Collection Port: For maintaining a clean and safe working environment.
-
Automatic Bag Placer: To upgrade the system toward full automation.
-
Integrated Sealing: Options for industrial sewing machines or heat sealers.
-
Conveyor Systems: Heavy-duty belts to move filled bags to the palletizing area.
Simple Operation. Reliable Weighing.
The ADDAMS Semi Automated Weighing and Bagging Scale brings efficiency, flexibility, and accuracy to open-mouth bagging, backed by rugged engineering and operator-friendly design.
Frequently Asked Questions – Bagging Scale
What bag types are compatible with this system?
The system supports a wide range of open-mouth bags, including woven polypropylene (PP), paper, Kraft, and PE-lined bags.
Can it handle both 5 kg and 50 kg bags on the same machine?
Yes. The digital controller allows you to adjust the target weight easily, and the bag clamp is designed to accommodate various bag widths.
How many bags can be filled per hour?
Depending on the product and operator speed, the system can reach capacities of 200 to 400 bags per hour.
Is this machine suitable for corrosive materials like salt or fertilizer?
Yes. For such applications, we recommend the AISI 304 or 316 stainless steel construction to ensure resistance against corrosion.
Does it require a compressed air supply?
Most models utilize pneumatic bag clamps and gates, so a standard industrial air compressor is typically required.
Can it be integrated with a sewing machine?
Absolutely. We often provide this scale as part of a complete line that includes a slat conveyor and an automatic bag sewing head.
