Other Pulses and Legumes Processing Solutions
ADDAMS designs complete cleaning, grading and handling systems for pulses and legumes beyond the main commercial crops. Each line is configured around the raw material, contamination profile, required capacity and final market specification. Whether the product is intended for food processing, seed production, export or animal feed, the objective is the same: remove foreign material efficiently while protecting the natural shape, colour and germination quality of the crop.
Related ADDAMS Equipment and Other Pulses Processing Guides
For pulse cleaning and quality separation, compare Fine Seed Cleaners, Gravity Separator and Optical Color Sorter. For dehulling or split products, review the separate de-hulling guide and splitting guide. Confirm crop-specific suitability and acceptable breakage.
Pulses differ greatly in size, density, surface condition and sensitivity to impact. A machine arrangement that performs well on a large bean may not be suitable for a small lentil, vetch or lupin. For this reason, ADDAMS evaluates samples and process targets before selecting screens, air settings, conveying equipment and separation stages.
Pulses and Legumes We Can Process
Our modular systems can be engineered for many specialty and regional products, including:
- Cowpeas, black-eyed peas and pigeon peas
- Lupins, vetch, mung beans and adzuki beans
- Broad beans, field beans and mixed bean varieties
- Specialty lentils, peas and chickpeas
- Feed legumes and locally grown pulse varieties
If your crop is not listed, our technical team can review a representative sample and define the appropriate process route.
Typical Pulse Cleaning Process
1. Reception and Pre-Cleaning
Raw pulses are received through a hopper and conveyed to a pre-cleaner. Coarse screens remove stalks, pods, strings and oversized material, while lower screens separate sand, broken particles and undersized impurities. An aspiration channel removes light dust, husk and empty seeds.
2. Fine Cleaning and Size Grading
A precision air-screen cleaner uses interchangeable screens to separate the crop by width and thickness. Multiple screen decks can produce uniform commercial fractions and reduce the load on downstream equipment. The selected screen perforations are based on sample analysis rather than a fixed crop assumption.
3. Density and Stone Separation
A Pressure De-Stoner removes stones, glass and heavy mineral contamination. Where damaged, immature or insect-affected pulses must be separated, an ADDAMS Vigor Series Gravity Separator classifies material according to specific weight. This stage improves purity and creates a more consistent final product.
4. Length, Shape and Colour Sorting
Depending on the crop and quality target, an indented cylinder can separate long or short contaminants. A spiral separator can classify round and irregular material by shape. Optical colour sorting can reject discoloured grains, foreign seeds and defects that cannot be identified by mechanical separation alone.
5. Product Handling and Packing
Clean product can be transferred to buffer bins, weighing systems, open-mouth bags or big bags. Belt conveyors, gentle bucket elevators and low-impact handling options are available for fragile crops and planting seed. Dust collection and centralized aspiration keep the working environment cleaner and support hygienic operation.
Equipment Commonly Used in Pulse Lines
- Intake hoppers, feeders and aspiration chambers
- Flat-screen, rotary-drum and vibratory pre-cleaners
- Fine screen cleaners and size graders
- Pressure De-Stoners and Vigor Series Gravity Separators
- Indented cylinders, spiral separators and magnetic separators
- Free-fall or belt optical colour sorters
- Bagging, big-bag filling, dust control and automation systems
Designed Around Your Product and Capacity
ADDAMS supplies individual machines as well as complete turnkey plants. Line capacity can range from compact seed-processing installations to industrial pulse-cleaning plants. The final configuration depends on bulk density, incoming moisture, percentage and type of impurities, required purity, available building height and the packaging format.
Before final engineering, we recommend a product test using a representative raw sample. Test results help determine the correct screen openings, airflow, deck inclination and machine sequence. This reduces unnecessary equipment and gives the customer a process designed around measurable separation results.
Why Choose ADDAMS for Specialty Pulses?
- Flexible, modular plant layouts that can be expanded
- Gentle handling options for food-grade and seed-grade products
- Process engineering from reception through final packing
- Integrated dust aspiration, electrical control and automation
- Installation, commissioning, training and spare-parts support
Send us your crop name, sample information, required capacity and final quality specification. Our engineering team will prepare a tailored process flow and equipment proposal for your pulses or legumes.
Contact ADDAMS for a customized pulse cleaning and grading solution.
